Probe

ASM 300

Prix normal
$4,425.00
Prix normal
Prix de vente
$4,425.00

Get 10% OFF: use code EARLYBF10

Frais d'expédition calculés à l'étape de paiement.
  • Dépêchez-vous 10 éléments en stock!

Analyse tout-en-un haut de gamme de la peau, du cuir chevelu et des cheveux

L'ASM 300 est le système d'analyse professionnel complet de Progen Probe pour les entreprises qui souhaitent évaluer la peau, le cuir chevelu, les cheveux et la cuticule capillaire à l'aide d'un seul appareil.

Le système comprend un écran tactile de 5,5 pouces, un logiciel d'analyse intégré et quatre objectifs interchangeables pour différents types d'analyse. Les quatre modules sont les objectifs ASM 100 Peau, ASM 202 Cheveux/Cuir chevelu, ASM 203 Cheveux et ASM 204 Cheveux/Cuticule.

Le grossissement varie de 30x jusqu'à 1000x, permettant aux professionnels de passer d'une analyse générale de la peau à un examen très détaillé des cheveux et de la cuticule.

ASM 300
ASM 300
ASM 300

Détails

Avantages

Offer a complete consultation experience without purchasing separate skin, scalp, and cuticle analyzers.

The built in touchscreen and software allow consultations to be performed directly from the ASM 300, while mirroring gives you the option to display results on a larger screen.

The ASM 300 also provides a more advanced hair thickness measurement than the APM PRO platform, allowing up to five hair strands to be measured and averaged for more detailed documentation.

Caractéristiques principales

  • Skin + scalp + hair + cuticle analysis
  • 30x to 1000x magnification
  • Four interchangeable analysis lenses
  • 5.5 inch touchscreen
  • Built in analysis software
  • Moisture & elasticity
  • Sebum
  • Pores
  • Melanin/pigmentation
  • Acne
  • Wrinkles
  • Skin sensitivity
  • Hair loss status
  • Scalp status
  • Hair density
  • Keratin/scalp buildup
  • Scalp sensitivity
  • Hair thickness
  • Hair pore status
  • Cuticle status
  • Up to 5 strand average hair thickness measurement
  • 3D imaging
  • Before & after comparison
  • Client progress tracking
  • Built in CRM/client database
  • Email results
  • Wi-Fi connectivity
  • Display mirroring

Best for: Advanced trichology practices, med spas, hair loss clinics, premium salons, hair replacement businesses, and businesses offering both skincare and hair/scalp consultations.

ASM 300

Mode d'emploi

ASM 300

User Manual

To learn how to use and set up the device, download the user manual.

Download user manual

Aram Viewer Software

The Aram Viewer analysis application provides visualization and analysis through high quality images of skin, scalp, and hair cuticle taken by the device's powerful magnification lenses. The application is only compatible with Progen Probe devices.

Download aram viewer software

Vidéos pédagogiques

En savoir plus sur l'appareil et sur la façon d'utiliser toutes ses fonctionnalités

Analysis Tutorial

Les vidéos pour cette section arrivent.

Demo

ASM 300 Demo

Setup

Les vidéos pour cette section arrivent.

Détails techniques

Processor ARM Cortex A7 (Octa core)
Memory eMMC 32 GB
OS Support Android 6.01 (Marshmallow)
Sensor pixel Total pixel: 5,038,848 / Effective pixel: 4,915,200
Image sensor Dual camera sensor - 1/4" color CMOS (5 Mega pixel) x1 camera sensor / High magnification
Image capture VGA: 640 x 480 / 5M: 2592 x 1944
LED Dip LED x8
High magnification lens ASM 100 - x30 / APM Pro-202 - x60 NL, x60 PL, x200 NL (Crop), x200 PL (Crop) / APM Pro-203 - x200, x600 (Crop) / APM Pro-204 - x500, x1,000 (Crop)
Lens Focus VCM Auto / Manual focusing
Weight 120 g
Cradle Battery Charger / File Transfer (USB interface)
Battery Type: Li-ION / Typical Capacity: 1,150mAh / Normal Voltage: 3.7V
Touchscreen C-touch TFT LCD 5.5" FHD (1080 x 1920)
Motion 3 Axis
Operating temperature -10 ~ 50°C
Storage temperature -30 ~ 50°C
Operating humidity 5 ~ 85%
